Summary
A memory unit, known as a 16-word nickel delay line, for a National-Elliott 405 computer system from the National Standards Laboratory, Sydney.
The 16-word nickel delay line was one of at least 20 such units used in the National-Elliott 405 computer and formed part of the Quick Access Store for temporary working storage of data. Delay lines were used in early computers.
Physical Description
A circuit board with four valves and various electronic components inside a square shaped aluminium housing with holes in two sides. There are 8 fine wires strung around a circular support disc inside the unit. There is a manufacturer's plate on one side of the unit and handwritten text in pencil, blue pen and black marker pen. There are three 8-socket "Jones type" connectors in one end of the unit.
More Information
-
Collecting Areas
-
Manufacturer
-
Inscriptions
Manufacturer's plate: " ELLIOT / UNIT CB / SERIAL NO. 896 " Handwritten, pencil: " RC. LEN [illegible] ", " -2 / 9-3-6 / 9 / 1/68 / 108K " Handwritten, blue pen: " 30 [degree symbol] gain " Handwritten, black marker: " 3 of 4 "
-
Classification
-
Category
-
Discipline
-
Type of item
-
Overall Dimensions
55 mm (Width), 370 mm (Depth), 370 mm (Height)
-
References
Details of Elliott computer systems, including pictures, in documents from website "Our Computer Heritage" SYSTEMS ARCHITECTURE FOR ELLIOTT 401, 402, 403 & 405 COMPUTERS, CCS-E2X2 - Issue 28, 2nd August 2006, Compiled by D. J. Pentecost [Link 1] - Retrieved 5 Oct 2010 (M. Vaughan) Delivery & Applications list of Elliott 401, 402, 403 & 405 computers, CCS-E2X1 - Issue 9 - 26th June 2006 [Link 2] - Retrieved 5 Oct 2010 (M. Vaughan)
-
Keywords
Circuit Boards, Computer Hardware, Computer Memory Devices, Electronics
