Summary
Triode designed for use as a grounded-grid frequency changer in radar receivers operating in the 1 to 3 GHz region. It has a 1.7 volt directly heated cathode. Used for both amplification and frequency changing.
Physical Description
Flanged copper clad steel envelope which has been sectioned to reveal a small directly heated triode structure with its grid connected to the envelope and its filament and anode brought out though four coaxial connections. The anode has two connections. Mounted on a display block.
More Information
-
Collecting Areas
-
Manufacturer
-
Inscriptions
On the envelope: WESTERN ELECTRIC (indistinct)/MADE IN U.S.A./708A On display block: Identification of valve and brief description of its applications
-
Classification
-
Category
-
Discipline
-
Type of item
-
Overall Dimensions
59 mm (Height), 48 mm (Outside Diameter)
Not including display block.
-
