Summary

Hollerith electric duplicating punch. Type 016 was produced from 1929 to 1960. The development of the duplicating machine was important as it could improve the accuracy of card production. This was useful for large card runs.

Physical Description

Key punch with electric motor fitted onto cast iron base with black japanned finish and curved legs; lid with three flanges to add strength in open position attached by three hinges on back section to cover the punch mechanism; this is probably a later addition as it is made of plain black metal sheet with chrome handle. Small micro-switch attached to the front of punch below the keys with red wire fed into the interior on right hand side adjacent to the card stack. Micro-switch made in Australia. This is also probably a later addition to modify the machine. On right hand side is a detachable chrome double H weight with screw to hold card stack. Separate black holder, on left hand side, was used to receive cards; presently detached. Side table extension could be attached to left hand side is missing. Two circular electric sockets in rear with pins. Power buttons on right hand edge Two buttons - one black/one white

More Information

  • Collecting Areas

    Information & Communication

  • Acquisition Information

    Unknown Acquisition Method from Unknown

  • Designer

    International Business Machines (IBM), United States of America, 1929-1960
    The date '1934' was in Object Summary before it was edited in 2013.

  • Inscriptions

    Key pad = three keys across by four keys down. Key pattern: Blank X 0 1 2 3 4 5 6 7 8 9 Machine plate number on right hand side behind card stack: "3501600228" Number on cast iron leg: "2008132" Number on cast iron below punch keys: "N848.333" Inscription on metal plate with impressed numbers: Volt 110 / Amp 0 / Periodes Phase Three punch cards in right hand stacker; cream card with B/W print; marked "Hollerith BTM England, Printed in Australia" Card no: 82-513-02-03

  • Classification

    Computing & calculating, Digital computing, Storage and retrieval

  • Category

    History & Technology

  • Discipline

    Technology

  • Type of item

    Object

  • Overall Dimensions

    900 mm (Width), 395 mm (Depth), 920 mm (Height)
    With lid closed.

  • Overall Dimensions

    900 mm (Width), 610 mm (Depth), 1075 mm (Height)
    With lid open.

  • References

    Hollerith Punch Card. Accessed 19 August 2013. [Link 1] Early Card Punch Machines. Accessed 19 Aug 2013. [Link 2] Keypunch. Accessed 19 Aug. 2013[Link 3]

  • Keywords

    Innovation & Design
