Summary
The Visual 100 display terminal consists of three basic assemblies: keyboard, video monitor and printer circuit board including a communication interface. The Visual 100 can be interfaced with various serial printers.
Physical Description
Cream coloured metal panels on three sides with louvres in the top panel. A CRT screen surrounded by dark brown metal panel. Blue Dymo label attached to panel underneath the screen. Four connectors at the rear for peripheral equipment, including keyboard. Grey plastic sheathed power cable with 3 pin plug. A service tag is attached to the cable. The keyboard has a white metal top panel with black keys and white letters and numbers. Keys also have printed stickers. Cream coloured electrical cable with 15 pin male connector.
More Information
-
Collecting Areas
-
Manufacturer
Zenith Radio Corporation, Chicago, Illinois, United States of America, 1981
-
Inscriptions
Underneath, manufacturer's plate: " VISUAL / ANDOVER, MA. 01810 / MODEL VISUAL 100 / SERIAL No. 004406100 / POWER 220 V 50 HZ 110W 0.5 AMP / NFPA TYPE II MADE IN U.S.A. " Underneath, sticker: " X-RAY EMISSION / DISPLAY MONITOR CONFORMS TO THE TECHNICAL / REQUIREMENTS OF D.H.H.S. RULES 21 CFR - SUB- / CHAPTER J APPLICABLE AT DATE OF MANUFACTURE / DATE OF MANUFACTURE: NOV 17 1981 / ZENITH RADIO CORP. / CHICAGO, ILL. 60639 " On top of keyboard, black: " VISUAL 100 "
-
Classification
-
Category
-
Discipline
-
Type of item
-
Overall Dimensions
432 mm (Width), 380 mm (Depth), 330 mm (Height)
Unit
-
Overall Dimensions
435 mm (Width), 210 mm (Depth), 70 mm (Height)
-
