Summary
Optocoupler (also known as Opto-isolator) device manufactured by Hewlett-Packard, 6N139. An optocoupler provides electrical isolation between circuits by using light. One half of the device contains a small light emitting element (typically a LED - Light Emitting Diode) which is optically connected (typically using glass) to a light sensitive element (photo-transistor). This allows siginalling between two circuits with electrical isolation. Often used in computer communication.
Physical Description
Small black rectangular plastic package with 8 gold-plated pins.
More Information
-
Collecting Areas
-
Manufacturer
Hewlett Packard, California, United States of America, circa 1978
-
Inscriptions
(logo) hp / 6N138 / 815 / UR
-
Classification
-
Category
-
Discipline
-
Type of item
-
Overall Dimensions
8 mm (Width), 13 mm (Depth), 4 mm (Height)
-
