Summary
Transmitting triode with a plate dissipation of 100 watts. Directly heated 5 volt filament.
Physical Description
Spherical glass bulb with two cylindrical necks top and bottom. The top neck carries a metal top cap for connection to the anode; the bottom neck carries an American 4 pin (UX) base with a ceramic body. A side arm on the bottom neck carries the grid connection.
More Information
-
Collection Names
-
Collecting Areas
-
Acquisition Information
Donation from K. Aitken, 1976
-
Manufacturer
Eitel-McCullough Inc., San Bruno, California, United States of America, 1943
-
Inscriptions
On bottom neck: EIMAC/Reg. U.S. Pat Off./Pat No. 2310769/100th - VT218/MADE IN U.S.A. On stem (inside valve): W3-51773 Note: The prefix to the serial number written on the pinch (W3) indicates that this valve was made in October 1943 at Eimac's Salt Lake City factory.
-
Classification
-
Category
-
Discipline
-
Type of item
-
Overall Dimensions
195 mm (Length), 78 mm (Outside Diameter)
-
References
See: ...\ Miscellaneous files\US2310769.pdf for patent application, note the beautiful drawings.
-
