Summary
Transmitting triode introduced by Philips in 1923. Capable of producing an output of 240 watts.
10 - 10.5 volt directly heated tungsten cathode.
This valve came from Mr Maxwell Howden via the Wireless Institute of Australia. An article in the 'Listener In' for January 24 1925 by Mr Howden shows one of these valves in use in his transmitter. It is reasonable to assume that this is the valve which he acquired in 1924.
Physical Description
Elliptical football shaped bulb with cylindrical ends, side-arm near top and exhaust tip opposite it. 2 pin standard bayonet cap at top (filament connection), plated metal caps with one contact on the side arm (grid connection) and the bottom (anode connection). Anode and grid caps have short flying leads attached.
More Information
-
Collection Names
-
Collecting Areas
-
Acquisition Information
Donation from Wireless Institute of Australia, Mr Max Howden, 28 Apr 1967
-
Manufacturer
-
Inscriptions
One side of bulb: PHILIPS Other side of bulb: Z4/976/MADE IN HOLLAND/Sold for Amateur Use only
-
Brand Names
-
Classification
-
Category
-
Discipline
-
Type of item
-
Overall Dimensions
330 mm (Length), 120 mm (Outside Diameter)
-
