Summary
Space charge tetrode. The space charge tetrode is operated with a positive voltage on the inner grid, the outer grid acts as the control grid. This configuration gives satisfactory performance at low anode voltage.
3.2 volt directly heated cathode.
The label on the base has been rendered illegible by staining from corrosion of the base shell hence it is not possible to positively identify this valve but based on comparison with Figure 12-18 in Tyne, it appears most likely that it is a type 110.
Manufacturer: Siemens & Halske, Germany
Physical Description
Conical bulb with exhaust tip. 5 pin base with 4 male pins and one female pin. Base shell has a paper label and badly corroded.
More Information
-
Collection Names
-
Collecting Areas
-
Acquisition Information
Donation from Wireless Institute of Australia, Mr Max Howden, 28 Apr 1967
-
Manufacturer
-
Inscriptions
Bulb paper label: (illegible) Base psper label; (illegible)
-
Brand Names
-
Classification
-
Category
-
Discipline
-
Type of item
-
Overall Dimensions
107 mm (Length), 42 mm (Outside Diameter)
-
References
[Book] Tyne, Gerald F. 1987. Saga of the Vacuum Tube., 1987, 245 - 246 Pages
-
