Summary
Two Power triodes primarily intended for telephone repeater use. Could produce nearly 18 watts under maximum rated conditions but usually operated at a much lower power level for maximum life. Equivalent to Western Electric 300A.
5 volt directly heated cathode.
Physical Description
Both valves are the same type and packed in the same style of box; the only differences between them are in the inscriptions on the valves and on the boxes. Description: Shouldered glass bulb with American type 4 pin (UX) base. A robust triode structure with a corrugated anode and a filament consisting of 4 inverted Vs is visible inside. The valve is packaged in its original cardboard carton. The valve is held in a closed fabric sleeve suspended by a four metal springs and some fabric tape supported by a wooden frame made from ½ inch square timber.
More Information
-
Collection Names
-
Collecting Areas
-
Acquisition Information
Donation from P. T. Brown, 20 Sep 1970
-
Manufacturer
Standard Telephone & Cables Ltd (STC Ltd), England, Great Britain, circa 1939
-
Inscriptions
On bulb: STC (logo)/4300A/F/(broad arrow). Part 1: On bulb: STC (logo)/4300A/F On pinch: PK 65 On one side of box: GLASS WITH CARE On adjacent side of box: WAR ECONOMY/RETURN WHEN EMPTY/TO/STANDARD TELEPHONES & CABLES LTD. On one end flap of box: 4300A/SER No (nothing visible) On other (closed) end of box: 4300A/F/G P O (faint) On wooden frame: 4300A Part 2: On pinch: PL(could be C) 10 On one side of box: GLASS WITH CARE On one end flap of box: 4300A/SER No (nothing visible) On other (closed) end of box: 4300A/F On wooden frame: 4300A
-
Classification
-
Category
-
Discipline
-
Type of item
-
Overall Dimensions
156 mm (Length), 59 mm (Outside Diameter)
Dimensions of box (mm): Length: 200, Width: 120, Depth: 120
-
