Item ST 35931 Electronic Valve - Philips, Triode - Hexode, Type ECH33, circa 1950

Summary

Triode-hexode used as a frequency changer in superheterodyne radio receivers. Used in the post-World War Two (1939-1945) years up to about 1952.
6.3 V indirectly heated cathode.
This was the octal based version of the side contact type ECH3. It was equivalent to the ECH35 except for its heater current rating (200mA versus 300mA for the ECH35)

Manufactured for: Philips, Holland
Manufacturer: Mullard, England

Physical Description

Shouldered red sprayed glass bulb with top cap and octal base

More Information

Collection Names

Electronic Valve Collection
Collecting Areas

Information & Communication, Engineering
Acquisition Information

Donation from Mrs M. Kennedy, by Feb 1986
Manufactured For

Philips, Holland, circa 1950
Manufacturer

Mullard, England, Great Britain, circa 1950
Inscriptions

Bulb: ECH33/MADE IN/GREAT BRITAIN Base: PHILIPS/Miniwatt/1041/1H3
Brand Names

Philips (Thermionic Electron Valves)
Classification

Electronics, Vacuum technology, Frequency changing
Category

History & Technology
Discipline

Technology
Type of item

Object
Overall Dimensions

110 mm (Length), 35 mm (Outside Diameter)
Keywords

Thermionic Electron Valves
