Summary
Early mains powered Tuned Radio Frequency (TRF) radio. The tuning coils are very large and mounted in copper shielding cans in order to achieve a very high Q and hence get adequate selectivity with the TRF design.
Physical Description
Wooden cabinet with a sloping front. There is a thumb-wheel tuning control on the main panel and 3 knobs and two levers on a small vertical panel at the bottom of the front. The knobs are the volume control, a band switch and an aerial trimming capacitor. The two levers each rotate one of the stators of the three gang tuning capacitor through a small angle. This was done to aid 'tracking' to make sure that all three tuned circuits are tuned to exactly the same frequency over the tuning range of the receiver.
More Information
-
Collecting Areas
-
Acquisition Information
Donation from Dr Marguerite Mahood, 25 Sep 1978
-
Manufacturer
-
Inscriptions
Just above the dial: Telefunken logo
-
Classification
-
Category
-
Discipline
-
Type of item
-
Overall Dimensions
555 mm (Width), 350 mm (Depth), 270 mm (Height)
-
