Item ST 30178 Electronic Valve - General Electric, Ignitron, Type FG-235-A, early 1930s

Summary

Controlled half wave rectifier (Ignitron). Mercury arc device used for the control of large AC currents in welders, magnetisers and similar equipment and as a controlled rectifier. Manufacturer: General Electric, USA

Physical Description

Cylindrial stainless steel tube with copper bar connector and light lead at one end and heavy copper braid lead at the other. Tube has input and output water connections. Thick glass tube is enclosed by the metal tube.

More Information

Collection Names

Electronic Valve Collection
Collecting Areas

Information & Communication, Engineering
Acquisition Information

Donation from Royal Melbourne Institute of Technology (RMIT), 14 Sep 1978
Manufacturer

General Electric Co (GE), United States of America, 1930-1934
Inscriptions

Metal cylinder: General(logo) Electric/FG-235-A/Made in USA/14130
Brand Names

GE (Thermionic Electron Valves)
Classification

Electronics, Vacuum technology, Rectification
Category

History & Technology
Discipline

Technology
Type of item

Object
Overall Dimensions

330 mm (Length), 104 mm (Outside Diameter)
