Summary

SC/MP microprocessor development system.

Comprises SC/MP microprocessor chip, read only memory (ROM), random access memory (RAM) and input- output logical function on board with facility for plug in boards, hexadecimal keypad, toggle switches to enable single step program debugging, light emitting diode (led) output, all mounted on box containing mains operated power supply.

Used for initial testing of hardware and software configurations in the early days of microprocessors. The kit can be used to build a microprocessor system. The system can be used for a variety of applications, for example, to control external lights or photographic lights, lawnsprinkler systems and security devices,

The development system is accompanied by extensive documentation on early operating systems, CP/M and CP-86, plus blank plug in boards for hardware lashups and electrically programmable read only memory (EPROM) board.

Made by National Semiconductor Corporation in the United States of America about 1976.

Physical Description

The system comprises SC/MP microprocessor chip, read only memory (ROM), random access memory (RAM) and input- output logical function on board with facility for plug in boards, hexadecimal keypad, toggle switches to enable single step program debugging, light emitting diode (led) output, all mounted on box containing mains operated power supply. Cardboard box containing three circuit boards and a chip: one circuit board with components in black plastic bag one board with components one board without components in transparent plastic bag single chip on foam pad, wrapped in paper Cardboard box containing two circuit boards without components; one board in plastic bag; both boards stuck with tape to inside of box. Extensive documentation - see Narrative entitled 'Contents of Documentation ( Operating Systems, CP/M & CP-86, circa 1976) - ST 041837.4'. .

More Information

  • Collecting Areas

    Information & Communication

  • Acquisition Information

    Donation from Mr Garry Page, 06 Jan 1994

  • Manufacturer

    National Semiconductor Corp, United States of America, circa 1976

  • Inscriptions

    System: Red plastic plate on top: SC/MP DEVELOPMENT SYSTEM / (logo) NATIONAL SEMICONDUCTOR CORPORATION Components, circuit boards, keypad: (text) Sticker on rear side: (logo) NATIONAL SEMICONDUCTOR CORPORATION / 7846 Serial No / 9904966 - TSP Part No / SP-301 Model No / 10 -1 - 76 Cardboard box with 3 boards & chip: Top: (logo) NATIONAL SEMICON(cut off) CORPORA(cut off) / (text) / 2900 SEMICONDUCTOR DRIVE Handwritten on side: ISP-8C/004B On transparent plastic bag contianicontainingoard: ISP 8C-870 On paper wrapping chip: PROM (1MHz) Clock Cardboard box containing two blank circuit boards: Top: (logo) NATIONAL SEMICON(cut off) CORPORA(cut off) / (text) / 2900 SEMICONDUCTOR DRIVE Handwritten on side: ISP8C-002N On transparent plastic bag containing empty board: ISP-8C-870 (1) Extensive documentation - see Narrative entitled 'Contents of Documentation ( Operating Systems, CP/M & CP-86, circa 1976) - ST 041837.4'.

  • Brand Names

    National Semiconductor (Microcomputers)

  • Classification

    Computing & calculating, Digital computing, Computer systems

  • Category

    History & Technology

  • Discipline

    Technology

  • Type of item

    Object

  • Overall Dimensions

    305 mm (Width), 335 mm (Depth), 215 mm (Height)
    Dimensions of system.

  • Part Dimensions

    113 mm (Width), 135 mm (Height)
    Approximate overall dimensions of each circuit board.

  • Part Dimensions

    30 mm (Width), 3 mm (Depth), 15 mm (Height)
    Dimensions of chip.

  • Keywords

    Computer Components, Computer Memory Devices, Computers, Computing, Electronics, Microcomputer Systems, Microprocessor Controls
