Summary
Two slug tuned broadcast band tuning coils, Q- PLUS brand, with original cardboard cases.
Made by R. W. Steane & Co. Pty. Ltd. in Australia, in 1948.
Coils have aerial, grid & feedback windings for regenerative receiver. For use with the Dr. Reinartz method of feeding energy from plate to grid of detector valve conferring vastly increased sensitivity.
Physical Description
Coils: rectangular aluminium can with square cross section, with six pin base, central fixing nut and adjusting screw. Boxes: rectangular cardboard box in yellow and black with red sash; printed text in black.
More Information
-
Collecting Areas
-
Acquisition Information
Unknown Acquisition Method from Unknown Source, 1980
-
Place & Date Made
-
Manufacturer
-
Inscriptions
On side of each coil: (logo) "Q+" / "REIN. -RC 6" On base of each coil: " B+ / A2 / G / F / A1 / P" Ends of each box: "Reinartz" / "COIL " / "Q PLUS" / "TYPE" / "R.C.6" Three sides of box: (pin connections for various coils except for the one inside the box!) Fourth side of box: "ASK FOR LARGE Q PLUS COILS," / "I.F.'s etc." / "MANUFACTURED AND GUARANTEED" / "BY" / "R.W.STEANE & CO. PTY. LTD., VICTORIA
-
Brand Names
-
Classification
-
Category
-
Discipline
-
Type of item
-
Box Dimensions
53 mm (Length), 25 mm (Width), 24 mm (Height)
Dimensions of each box.
-
Part Dimensions
48 mm (Length), 20 mm (Width), 20 mm (Height)
Dimensions of each coil.
-
