Summary
Portable diamond drilling machine operated by steam or compressed air, designed for prospecting work in the mining industry (particularly underground).
Believed to have either been manufactured by the Sullivan Machinery Company of Chicago, Illinois, U.S.A. for the Goldfields Diamond Drilling Company, of South Melbourne, around the 1920s or built in Victoria based on a Sullivan Machinery Co. design, possibly with some imported components. Complete with engine, winch & hydraulic-cylinder boring head, but missing boring rod & diamond drill bit, mounted on wooden frame. Restored to operating condition by Scienceworks engineering workshop, about 1995.
Physical Description
Diamond Drilling Machine complete with engine, winch & hydraulic-cylinder boring head, but missing boring rod & diamond drill bit, mounted on wooden frame.
More Information
-
Collecting Areas
-
Acquisition Information
Donation from Mr Albert H.J. Bienvenu, 23 Aug 1994
-
Manufacturer (Probable)
Sullivan Machinery Company, Chicago, Illinois, United States of America, 1900-1939
Engine & winch section of the machine appears to be of a standard Sullivan design. -
Patentee
Goldfields Diamond Drilling Co. Pty Ltd, Melbourne, Greater Melbourne, Victoria, Australia, 1920-1935
Rotary drilling head patented by Goldfields Diamond Drilling Co. Ltd. -
Inscriptions
Cast into circular plate on steam chest of winch engine: 'No 617' Cast into cylinder of drilling head: 'G.D.D. Co, LTD. / PATENT / MELBOURNE' Cast into indicator plate beside drilling head: 'C.C.'
-
Classification
Mining & metallurgy, Exploration & prospecting - general, Diamond drilling machines
-
Category
-
Discipline
-
Type of item
-
Overall Dimensions
1900 mm (Length), 1300 mm (Width), 2900 mm (Height)
Dimensions are approximate.
-
Keywords
Diamond Drills, Economic Geology, Gold Mining, Mining, Mining Machinery, Prospecting, Steam Engines
