Summary
Two basket coils, one in green wire and the other in brown. Used in radio receivers, basket coils were wound in such a way as to minimise the self-capacitance of the coil. This green wound coil was used in very long wave receivers; the brown was used in long wave. Basket coils were a popular form of inductor in the early 1920s.
Physical Description
Two different sized circular coils, each with a criss-cross winding, clamped by a circumferential strap, which is attached to a red fibre block with one pin and one socket connection. The smaller coil is wound with brown wire and the larger coil is wound with green wire
More Information
-
Collecting Areas
-
Acquisition Information
Purchase (Probable)
-
Date Manufactured
-
Classification
-
Category
-
Discipline
-
Type of item
-
Part Dimensions
131 mm (Length), 95 mm (Width), 29 mm (Depth)
Dimensions of Part 1, brown wire coil
-
Part Dimensions
160 mm (Length), 128 mm (Width), 27 mm (Depth)
Dimensions of Part 2, green wire coil.
-
