Summary
Output pentode introduced by Marconi-Osram in 1929. The 4 pin base carried the filament, plate and control grid connections; the screen connection was a side terminal. This was done so that the valve could be used in place of a triode by simply plugging it in and connecting the side terminal to the plate supply. 4 volt directly heated cathode. Used as a Class A power output amplifier.
Physical Description
Internal structure of an output pentode with its bulb removed which has suffered some damage. Mounted on an American style 4 pin (UX) base with a side terminal.
More Information
-
Collection Names
-
Collecting Areas
-
Acquisition Information
Donation from R. Barr, 10 Jul 1947
-
Manufacturer
-
Inscriptions
Display block: PT425 OUTPUT PENTODE/Osram Made in England/(Brief description)/Pres. by R. Barr
-
Brand Names
-
Classification
-
Category
-
Discipline
-
Type of item
-
Overall Dimensions
100 mm (Length), 35 mm (Outside Diameter)
Display block not included.
-
