Summary
General purpose triode with a directly heated cathode designed to be operated from an AC supply. 1.5 volt directly heated cathode which drew a current of 1 amp.
Equivalent to the RCA UX226.
The combination of low voltage and high current in the filament was designed to minimise hum. It was used in the RF amplifier and audio stage in the earliest AC mains powered radios. Rendered obsolete by the development of economical indirectly heated valves.
Manufacturer: Philips, Holland.
Physical Description
Conical bulb on 4 pin UX style base; mounted on display block with ST 22544.
More Information
-
Collection Names
-
Collecting Areas
-
Acquisition Information
Donation from R. I. Henry, 17 Feb 1947
-
Manufacturer
-
Inscriptions
Bulb: PHILIPS/MINIWATT/F109/SOLD FOR AMATEUR USE ONLY/MADE IN HOLLAND Display block: (text)
-
Brand Names
-
Classification
-
Category
-
Discipline
-
Type of item
-
Overall Dimensions
98 mm (Height), 45 mm (Outside Diameter)
Dimensions of valve, excluding display block.
-
