Summary
Two dual diode triode in which the diode sections were used for the signal detector and automatic volume control (AVC) rectifier and the triode section was used for the first audio stage in radio receivers. Replaced by octal type 6B6-G. One made by National Union and the other by RCA. 6.3 volt indirectly heated cathode.
Physical Description
Shouldered glass bulb with top cap and American style 6 pin base. Mounted on display block with a sectioned example of the same type.
More Information
-
Collection Names
-
Collecting Areas
Engineering, Information & Communication, Public Life & Institutions
-
Acquisition Information
Purchase
-
Manufacturer
-
Manufacturer
-
Inscriptions
Bulb: 75 Base (printed): NATIONAL/UNION Base (hot stamped): 4 (assumed date code for 1934) Display block: Description and name of donor. Bulb: MADE IN/75/U.S.A. Base (hot stamped on side): RCA (logo)/Cunningham/Radiotron Base (hot stamped underneath): J15 (Date code) Display block: Description and brief data
-
Classification
Electronics, Vacuum technology, Amplification & rectification
-
Category
-
Discipline
-
Type of item
-
Overall Dimensions
114 mm (Length), 38 mm (Outside Diameter)
National Union valve; display block not included
-
Overall Dimensions
113 mm (Length), 38 mm (Outside Diameter)
RCA valve: display block not included
-
