Summary
Rectifier diode designed for use in AC/DC radios. The heater was tapped to provide a suitable voltage for a dial lamp. 35 V indirectly heated cathode. Used as half-wave rectifier (without panel lamp).
Physical Description
Vertical metal and mica electrode structure of a diode valve with its bulb removed. Loctal base with 5 pins present. Mounted on display block.
More Information
-
Collection Names
-
Collecting Areas
-
Acquisition Information
Donation from J. C. Liddy, 27 Apr 1951
-
Manufacturer
-
Inscriptions
Display block: Description and brief electrical characteristics.
-
Brand Names
-
Classification
-
Category
-
Discipline
-
Type of item
-
Overall Dimensions
69 mm (Length), 30 mm (Outside Diameter)
Dimensions not including display blck
-
