Summary
The pentode section of this valve was primarily intended for use as an intermediate frequency (I.F.) amplifier, the diode sections were used as signal detector and automatic volume control (A.V.C.) rectifier. The pentode section was also frequently used as the first audio stage. 6.3 volt indirectly heated cathode. Used as class a r.f. amplifier.
Physical Description
Sectioned shouldered glass bulb with top cap and octal base base mounted on display block.
More Information
-
Collection Names
-
Collecting Areas
-
Acquisition Information
Donation from J. C. Liddy, 14 Mar 1950
-
Manufacturer
Australian Wireless Valve Co (AWV Co), Australia, 1940-1945
Valves branded 'Ken-Rad' were manufactured by AWV during the early 1940s. The statement about Ken-Rad on the display block is not correct for this valve. -
Inscriptions
Display block: DUO-DIODE-PENTODE 6B8G/Radiotron Made in Australia/Kenrad Made in U.S.A./Heater Cathode; 6.3 volt, 0.3 amp./Used as second detector in Superhet./Receivers/Pres. by A.W.A. and J.C.Liddy
-
Brand Names
-
Classification
-
Category
-
Discipline
-
Type of item
-
Overall Dimensions - Folded
90 mm (Length), 38 mm (Outside Diameter)
Dimensions not including display blck
-
