Summary
Two HeptodeType 2A7 Electronic Valves, circa 1934; one manufactured by Hygrade and the other by Ken-Rad. The heptode or pentagrid converter combined the functions of local oscillator and mixer in the one valve. The 6A7 is same valve with a 6.3 volt heater. 2.5 volt indirectly heated cathode.
Physical Description
Intact valve: shouldered glass bulb with top cap and American small 7 pin base. Mounted on display block with a sectioned example of the same type of valve. Sectioned valve: sectioned shouldered glass bulb with top cap and American small 7 pin base. Mounted on display block with a complete example of the same type of valve
More Information
-
Collection Names
-
Collecting Areas
-
Acquisition Information
Donation from C. G. McGlinn, 19 Jan 1949
-
Manufacturer
Hygrade, United States of America, circa 1934
Manufacturer of intact valve. -
Manufacturer
The Ken-Rad Corporation, United States of America, circa 1934
Manufacturer of sectioned valve -
Inscriptions
Intact valve: Base: Hygrade Sectioned valve: Sectioned shouldered glass bulb with top cap and American small 7 pin base. Mounted on display block with a complete example of the same type of valve. Base: Ken-Rad/D K 1 Display block: Brief Description.
-
Brand Names
-
Classification
-
Category
-
Discipline
-
Type of item
-
Part Dimensions
116 mm (Length), 38 mm (Outside Diameter)
Overall Dimensions of intact valve, excluding display block.
-
Part Dimensions
114 mm (Length), 38 mm (Outside Diameter)
Overall Dimensions of sectioned valve, excluding display block.
-
