Summary
Tetrode (usually called a screen-grid valve in its day) designed for use as a radio frequency (RF) amplifier in AC mains powered equipment. The use of a screen grid between the control grid and the plate reduced the grid-plate capacitance and permitted high gain at radio frequencies without stability problems. 2.5 volt indirectly heated cathode.
Physical Description
Conical glass bulb with top cap and American style 5 pin (UY) base. Mounted on display block with a sectioned example of a similar valve.
More Information
-
Collection Names
-
Collecting Areas
-
Acquisition Information
Purchase
-
Manufacturer
-
Inscriptions
Bulb: Made In Holland/PHILIPS/PH/224 Display block: TETRODE (Screen Grid R.F.) 224/(List of makers)/(Brief description)
-
Brand Names
-
Classification
-
Category
-
Discipline
-
Type of item
-
Overall Dimensions
124 mm (Length), 35 mm (Outside Diameter)
Not including display block.
-
