Summary
Pentode used in the output stages of radios, amplifiers and other equipment requiring a moderate amount of power. 6.3 volt indirectly heated cathode. Used as class A power output amplifier, either single ended or pushpull.
Mounted on a display block: some of the information on the display block is incorrect. The heater current is actually 0.7 A and the maximum power for a single valve is only 3.1 W.
Physical Description
Tubular metal envelope. Octal base with 7 pins present. Mounted on display block with a sectioned example of the same type (ST 022870)..
More Information
-
Collection Names
-
Collecting Areas
-
Acquisition Information
Purchase
-
Manufactured For
-
Inscriptions
Envelope: MADE IN/U.S.A./PHILIPS/6F6 Display block: Description and name of donor.
-
Brand Names
RCA (Thermionic Electron Valves) , Radiotron (Thermionic Electron Valves)
-
Classification
-
Category
-
Discipline
-
Type of item
-
Overall Dimensions
80 mm (Length), 33 mm (Outside Diameter)
Dimensions not including display blck
-
