Summary
'Magic Eye' tuning indicator. It had a green display with a dark fan shaped area in the centre, the width of which depends in the voltage applied to the control grid of the valve. Zero volts give the maximum shadow width and -14 volts closes it completely.
The inscription 'FOREIGN' almost certainly indicates that the valve was made by the ITT subsidiary Lorenz AG in Germany for the British ITT subsidiary STC.
Manufactured for: STC, England (Brimar trademark). Probable manufacturer: Lorenz, Germany.
6.3 volt indirectly heated cathode.
Physical Description
Tubular glass bulb with exhaust tip on top with nine pin miniature configuration.
More Information
-
Collection Names
-
Collecting Areas
-
Acquisition Information
Donation from P. Bullen, 02 Mar 1982
-
Manufactured For
Standard Telephone & Cables Ltd (STC Ltd), England, Great Britain, 1955-1965
-
Manufacturer (Probable)
-
Inscriptions
BRIMAR/(BVA logo)/EM85/FOREIGN Paper label handwritten: T53/From/P. Bullen/2-3-82
-
Brand Names
-
Classification
-
Category
-
Discipline
-
Type of item
-
Overall Dimensions
65 mm (Length), 21 mm (Outside Diameter)
-
