Summary
6.3 V indirectly heated cathode, manufactured by the Hygrade Sylvania Corporation, Emporium, PA, USA, 1940-1945.
The 7C7 is a sharp cut-off pentode designed for use in airborne and other receivers subject to shock and vibration. It has similar characteristics to the 6J7 but uses about half the heater current.
The Loctal base fitted to this valve has a detent on the locating spigot which prevents the valve from coming out of its socket when subjected to vibration such as that encountered in aircraft equipment.
The JAN/CHS prefix indicates that this valve was made for the United States military. VT-193 is the U.S. Army designator for this valve.
Physical Description
Tubular glass bulb on loctal base.
More Information
-
Collection Names
-
Collecting Areas
-
Acquisition Information
Unknown Acquisition Method from Unknown Source, 1981
-
Manufacturer
Hygrade - Sylvania Corporation., Emporium, Pennsylvania, United States of America, 1940-1945
-
Inscriptions
Top of bulb: 7C7 Side of bulb: JAN CHS 7C7/VT-193/SYLVANIA/MADE IN U. S. A./SC/95/A Paper label on bulb: 7C7
-
Brand Names
-
Classification
-
Category
-
Discipline
-
Type of item
-
Overall Dimensions
68 mm (Length), 30 mm (Outside Diameter)
-
