Summary
6AG5 pentode. Miniature sharp cut-off pentode mainly used as an RF or IF amplifier in radar and television receivers. Useful up to 400 MHz. 6.3 volt indirectly heated cathode at 300 ma, similar to 6BC5, manufactured by RCA, Harrison, NJ, USA, 1942-1960.
Physical Description
Base type: button No. of pins in base: 7 Bulb shape: miniature cylindrical with top exhaust tip Bulb material: glass
More Information
-
Collection Names
-
Collecting Areas
-
Acquisition Information
Unknown Acquisition Method from Unknown Source, 03 Oct 1978
-
Manufacturer
Radio Corporation of America (RCA), Harrison, New Jersey, United States of America, 1942-1960
-
Inscriptions
Bulb: 6AG5 / (RCA logo) / JRC-6AG5 / MADE IN / U.S.A.
-
Brand Names
-
Classification
-
Category
-
Discipline
-
Type of item
-
Overall Dimensions
53 mm (Length), 18 mm (Outside Diameter)
-
