Summary
Vidicon for general use in closed circuit television (CCTV) and educational television cameras.
Vidicon tubes were the most economical camera tubes available before the advent of semiconductor imaging devices. They were widely used in hand-held television cameras and industrial applications. The image is focused on a photoconductive faceplate and is converted to an electrical signal by being scanned by an electron beam.
Manufacturer: Nippon Electric (NEC), Japan.
6.3 volt indirectly heated cathode.
Physical Description
Tubular bulb with 8 pin base and image plate at other end. Exhaust tip in base. Getter has turned white indicating vacuum is lost.
More Information
-
Collection Names
-
Collecting Areas
-
Acquisition Information
Donation from Telesonics Pty Ltd, 09 Nov 1971
-
Manufacturer
-
Inscriptions
Bulb: Nippon Electric/(NEC logo)/7038/H
-
Brand Names
Hitachi (Thermionic Electron Valves) , Vidicons (Thermionic Electron Valves)
-
Classification
-
Category
-
Discipline
-
Type of item
-
overall dimensions
156 mm (Length), 29 mm (Outside Diameter)
-
