Summary
Output pentode, used as a Class A power output amplifier and a Class AB1 amplifier.
Philips developed the pentode (they spelled it penthode) for audio output applications in 1927. The E443N was released in 1928; it was designed for AC operation and could produce an output of over 5 watts with a plate supply of 400 V. It was replaced soon after by the E443H which could produce an adequate output with a more convenient 250 V supply.
Manufacturer: Philips, Holland.
4 V directly heated cathode.
Physical Description
Conical bulb with 5 pin UY style base.
More Information
-
Collection Names
-
Collecting Areas
-
Acquisition Information
Donation from Telesonics Pty Ltd, 09 Nov 1971
-
Manufacturer
-
Inscriptions
Bulb: Philips Miniwatt/Penthode/E443N/Made in Holland Base: (Paper Label re test)/E443N (in pencil)
-
Brand Names
-
Classification
-
Category
-
Discipline
-
Type of item
-
Overall Dimensions
119 mm (Length), 56 mm (Outside Diameter)
-
References
[Book] Stokes, John. 1982. 70 Years of Radio Tubes and Valves., 55 Pages
-
