Summary
The 6BQ6 was used as the horizontal deflection amplifier in television receivers.
It has a 6.3 volt indirectly heated cathode.
The 6BQ6GTB is the same as the 6BQ6GT except that it has a higher peak plate voltage rating, making it identical to the 6CU6, hence the dual marking.
Manufactured for: Philips (Australia)
Almost certainly manufactured by AWV as this was not a Philips type.
The valve has two grids and a pair of beam forming plates, which achieves the same result as the suppressor grid in a pentode.
Physical Description
Tubular glass bulb with top cap. Octal base with 7 pins present.
More Information
-
Collection Names
-
Collecting Areas
-
Acquisition Information
Donation from Telesonics Pty Ltd, 09 Nov 1971
-
Manufactured For
-
Manufacturer (Probable)
Australian Wireless Valve Co (AWV Co), Sydney, New South Wales, Australia, 1962-1970
-
Inscriptions
Bulb: 6BQ6GTB/6CU6 Base: Miniwatt/MADE IN AUSTRALIA
-
Brand Names
-
Classification
-
Category
-
Discipline
-
Type of item
-
Overall Dimensions
97 mm (Length), 32 mm (Outside Diameter)
-
