Summary
The 1D4 is a power output pentode with a 2 volt filament designed to be run from a single lead-acid cell or a pair of zinc-air batteries in series. It was a member of a family of valves that appear to have been unique to Australia. They were designed for farm radios that were operated from batteries in places without mains power. It has a 2 Volt directly heated cathode and was used as a class A power output amplifier.
Manufactured by: Amalgamated Wireless Valve Company (AWV), Sydney, Australia.
Physical Description
American style (UY) 5 pin base with glass bulb removed
More Information
-
Collection Names
-
Collecting Areas
-
Acquisition Information
Donation from Telesonics Pty Ltd, 25 Nov 1971
-
Manufacturer
Amalgamated Wireless Valve Company, Sydney, New South Wales, Australia, 1935-1939
-
Inscriptions
Base:Radiotron/MADE IN AUSTRALIA/(excise marking)1(over)4(scratched)
-
Brand Names
-
Classification
-
Category
-
Discipline
-
Type of item
-
Overall Dimensions
105 mm (Length), 35 mm (Outside Diameter)
-
