Summary
Beam Tetrode primarily designed for transmitting purposes but also widely used in high powered audio amplifiers. It is essentially the same as the type 6L6G except that it has the plate brought out to a top cap to handle high peak voltages and a 5 pin UY style base. The internal structure is also better insulated. 6.3 V indirectly heated cathode.
These valves were very popular with radio amateurs (hams) in the post war years. They were used in huge quantities in military equipment during the war, resulting in them being available in large quantities from disposals sources afterwards. The ham's slang term for a bottle of beer was 'an 807' as in 'I think I'll crack an 807'.
Manufacturer: Radio Corporation of America, Harrison, New Jersey, USA.
Physical Description
Shouldered glass bulb with top cap and low loss phenolic five pin base
More Information
-
Collection Names
-
Collecting Areas
-
Acquisition Information
Transfer from Science Museum of Victoria (SMV), 01 Aug 1971
-
Manufacturer
Radio Corporation of America (RCA), Harrison, New Jersey, United States of America, 1940-1949
-
Inscriptions
Bulb: 807/U.S.A./LRB Base: RCA/Radiotron/ELECTRON TUBE/(RCA LOGO)/MADE IN U.S.A.
-
Brand Names
-
Classification
-
Category
-
Discipline
-
Type of item
-
Overall Dimensions
142 mm (Length), 51 mm (Outside Diameter)
-
