Summary
Beam tetrode widely used for the audio output stage in radios, television receivers, amplifiers and numerous other applications. Introduced in 1946 it remained in use until the end of the 1960s (the year symbol of the date code is illegible).
It was the 7 pin miniature version of the octal 6V6 (G or GT). Known as the EL90 in Europe.
6.3 volt indirectly heated cathode.
Manufacturer: Philips, Hendon, South Australia.
Physical Description
Tubular glass bulb on seven pin miniature glass button base with top exhaust tip. Valve is contained in rectangular yellow and blue coloured cardboard box with fixed internal cardboard packing.
More Information
-
Collection Names
-
Collecting Areas
-
Acquisition Information
Transfer from Science Museum of Victoria (SMV), 01 Aug 1971
-
Manufacturer
Philips Electrical Industries Pty. Ltd., Hendon, South Australia, Australia, 1950-1966
-
Inscriptions
Bulb: 6AQ5/"Miniwatt"/MADE IN AUSTRALIA/542/(illegible)N(illegible)F All sides of box: (Philips logo)/"Miniwatt"/ELECTRON VALVE One side of box: (handwriting)(illegible)A Co/14-8-67 End of box: 6AQ5/MADE IN AUSTRALIA/"Miniwatt" End of box: "Miniwatt"/ELECTRON/VALVE
-
Brand Names
-
Classification
-
Category
-
Discipline
-
Type of item
-
Overall Dimensions
92 mm (Width), 24 mm (Depth), 24 mm (Height)
Dimensions of box containing valve.
-
Part Dimensions
67 mm (Length), 18 mm (Outside Diameter)
Dimensions of valve only.
-
