Summary
Pentode designed for use as a line-output (horizontal output) amplifier valve in television receivers. Also known as EL81.
Line-output valves drive the horizontal scanning coils of a television receiver. During the line scan period the valve must pass a relatively high current with a low voltage drop and during the flyback period it must withstand a high voltage while turned off.
Manufacturer: Mullard, UK.
6.3 V indirectly heated cathode.
Physical Description
Tubular bulb with 9 pin miniature base with top cap.
More Information
-
Collection Names
-
Collecting Areas
-
Acquisition Information
Transfer from Science Museum of Victoria (SMV), 01 Aug 1971
-
Manufacturer
-
Inscriptions
Bulb: Mullard/860/6CJ6/Made in Great Britain (partially rubbed off)/88F2
-
Classification
-
Category
-
Discipline
-
Type of item
-
Overall Dimensions
80 mm (Length), 20 mm (Outside Diameter)
-
