Mechanical diagram in hard copy relating to the computer CSIRAC.

Mechanical drawings show the physical construction of a component. They were used to define what was required in the manufacture of CSIRAC's hardware.

Technical details:
Mechanical Drawing. Subsystem: Input - Output. Drawn/checked by H. Peddie
Original Ink on Tracing Paper
Unit: 1243; Assy: C24030; C.P.L.:24031;
Scale: full size

Description of Content

Mechanical Drawing Original Ink on Tracing p. Subsystem: Input - Output Drawings Comments: Unit: 1243; Asyy: C24030; C.P.L.:24031; Scale: full size
