Summary
Keying Relay made by Amalgamated Wireless (Australasia) Ltd for a radio transmitter, circa 1914.
The relay is a safety device isolates the operator's morse key from the high voltage needed to operate the transmitter. The hand operated morse key switches the current through the coils on and off; activating the armature of the relay, thereby switching the high voltage (safely) to the transmitter.
Physical Description
Two solenoid coils mounted on wooden base with adjustable armature mechanism and terminals. Every major component has a letter on it.
Significance
The equipment is typical of early shipboard radio in the period prior to the First World War (1914 - 1918); it is rare.
More Information
-
Collecting Areas
-
Acquisition Information
Purchase
-
Manufacturer
Amalgamated Wireless (Australasia) Ltd (AWA), Sydney, Greater Sydney, New South Wales, Australia, circa 1914
-
Inscriptions
Metal plate on one side of wooden base: AMALGAMATED WIRELESS (AUSTRALASIA) LTD / MARCONI TELEFUNKEN SYSTEM / SYDNEY. NSW. No 97/313 Stamped into same side of wooden base: TESTED 07-A Metal plate on other side of wooden base: AUSTRALIAN MANUFACTURE Brass plate on top of box: ALTERNATOR Brass plate on top of box: TRANSFORMER Brass plate on top of box: CONDENSER Brass plate on top of box: FUSE Brass plate on top of box: 2 KEY 1 Component letters: A(magnetic part of armature) / E(both coils) / F(mounting block) / C(top contact) / K(bottom contact) / N(contact support) / R(adjuster support) S(adjuster screw) / J(contact carrying part of armature)
-
Brand Names
-
Classification
-
Category
-
Discipline
-
Type of item
-
Overall Dimensions
185 mm (Length), 160 mm (Width), 130 mm (Height)
-
Maximum dimensions
187 mm (Length), 160 mm (Width), 126 mm (Height)
Measurement From Conservation.
-
