Summary
General purpose high vacuum triode with an unusual planar construction.
2.7 volt directly heated cathode.
Manufacturer: AEG-Telefunken, Germany
Physical Description
Cylindrical glass bulb with insulating base. 4 pin Telefunken style base with three male pins and one female pin. Paper band in a channel around the base. This valve had a planar structure with a flat circular anode with a flat spiral grid above it and a catenary filament above that.
More Information
-
Collection Names
-
Collecting Areas
-
Acquisition Information
Donation from Wireless Institute of Australia, Mr Max Howden, 28 Apr 1967
-
Manufacturer
-
Inscriptions
Bulb: Telefunken/DRP/TypeEVN171/Nr 191286-1 Base(paper band): Gepruft/(illegible)/In Betrieb/Unbrauchbar The letters "EVN" in the type number mean: Empfänger Verstärker Niederfrequenz - Receiver Amplifier Low frequency. The inscription on the base: "In Betrieb Unbrauchbar" literally means "In enterprise useless" which may be equivalent to the common English inscription: "For Amateur Use Only".
-
Classification
-
Category
-
Discipline
-
Type of item
-
Overall Dimensions
116 mm (Length), 42 mm (Outside Diameter)
-
References
[Book] Tyne, Gerald F. 1987. Saga of the Vacuum Tube., 1987, 248 - 250 Pages
-
