Summary
Beam tetrode designed for use as a line-output (horizontal output) valve in television receivers.
Line-output valves drive the horizontal scanning coils of a television receiver. During the line scan period the valve must pass a relatively high current with a low voltage drop and during the flyback period it must withstand a high voltage while turned off.
Manufacturer: Standard Telephones & Cables Ltd., Footscray, Sidcup, Kent, UK. The base of the valve has 'Brimar' inscribed on it. Brimar was the brand name used by STC for radio receiving type valves.
6.3 V indirectly heated cathode.
Physical Description
Shouldered bulb with octal base and large top cap.
More Information
-
Collection Names
-
Collecting Areas
-
Acquisition Information
Transfer from Science Museum of Victoria (SMV), 01 Aug 1971
-
Manufacturer
Standard Telephones & Cables Ltd (S.T.C.), Footscray, Sidcup, Kent, England, Great Britain, 1950-1959
-
Inscriptions
Bulb: 6BG6G/2C8 Base: Brimar/Made in England
-
Brand Names
-
Classification
-
Category
-
Discipline
-
Type of item
-
Overall Dimensions
138 mm (Length), 51 mm (Outside Diameter)
-
