Item ST 28633 Telegraph Switch - Reversing, Unknown Make, Melbourne Observatory, Victoria, circa 1850s-1890s

Summary

A switch used for reversing small currents in telegraphy. Used at Melbourne Observatory.

Physical Description

Wooden base carrying two fixed and two pivoted brass connecting strips. Two pivoting strips are controlled by tension springs. Base also carries a pivoted brass switching lever fitted with an ebonite knob. Switching lever operates against one or other of the spring-loaded connecting strips to make or break either of two circuits. Three brass screw terminals for circuit connections.
